Reference Projects Pipelines and Plants

Horizontal Directional Drilling (HDD)

Horizontal Directional Drillings for Water Pipeline Bogen/Straubing (Germany)

Execution of horizontal directional drillings under the rivers Kinsach and Danube in the area of Bogen/Straubing; expansion of the local drinking water supply
Total length: about 1,800 m (one drilling of 200 m, two drillings of 800 m each), DN 200 or DN 400
Directional drilling method; use of the self-developed, fully electric driven horizontal directional drilling rig HDD80-E

PDF

Western Route Export Pipeline Project (Azerbaijan)

Construction of export route for crude oil from the Sangachal Terminal
in Azerbaijan to the Black Sea loading terminal at Supsa in Georgia
Lengths: 748 m, 945 m, 1,291 m

PDF

SCPX Project (Azerbaijan)

Scope of Work:
Execution of five river crossings for the installation of a 48" pipe using the HDD method

Lengths: 645 m, 703 m, 867 m, 964 m, 616 m

Devil Creek Development Project (Western Australia)

Scope of Work:
Shore approach for the installation of a 16’’ gas pipeline, pipeline construction and commissioning

Length: 2,100 m

PDF



Pipeline Connection Mittelplate (Germany)

Scope of Work:
Connection between offshore drilling platform Mittelplate and onshore facility with five HDD rigs

Lengths: 15,000 m; 6 sections
Diameter: 10", 6"

PDF



Natural Gas Storage Facility Jemgum (Germany)

Scope of Work:
Crossing of landscape protected area with two 350 t HDD rigs

Lengths: 1,716 m, 1,663 m, 1,528 m
Diameter: well 48“, pipe DN 900

PDF
